Vehicle-mounted solutions
Home
Datasheet Download
| Model | Rated voltage | Voltage range | Speed | Power | Air volume | Air volume | Air pressure | Noise | Curve | Weight | ||
| VDC | VDC | RPM | A | W | CFM | M3/h | mmH2O | mmH2O | dBA | Color | G | |
| FD1238B6U-AT00 | 48 | 43.6~52.8 | 5000 | 0.80 | 38.40 | 216.69 | 368.16 | 25.86 | 1.02 | 68.7 | Black | |
| FD1238B6H-AT00 | 4000 | 0.45 | 21.60 | 169.40 | 287.81 | 16.76 | 0.66 | 59.6 | Red | |||
| FD1238B6M-AT00 | 3000 | 0.30 | 14.40 | 125.93 | 213.96 | 9.19 | 0.36 | 52.4 | Green | |||
| FD1238B6L-AT00 | 2000 | 0.20 | 9.60 | 84.30 | 143.23 | 4.04 | 0.16 | 42.1 | Blue | |||
| FD1238B4U-AT00 | 24 | 12~26.4 | 5000 | 1.60 | 38.40 | 216.69 | 368.16 | 25.86 | 1.02 | 68.7 | Black | |
| FD1238B4H-AT00 | 4000 | 1.00 | 14.40 | 169.40 | 287.81 | 16.76 | 0.66 | 59.6 | Red | |||
| FD1238B4M-AT00 | 3000 | 0.40 | 9.60 | 125.93 | 213.96 | 9.19 | 0.36 | 52.4 | Green | |||
| FD1238B4L-AT00 | 2000 | 0.30 | 7.20 | 84.30 | 143.23 | 4.04 | 0.16 | 42.1 | Blue | |||
| FD1238B2U-AT00 | 12 | 6~14 | 5000 | 2.00 | 24.00 | 216.69 | 368.16 | 25.86 | 1.02 | 68.7 | Black | |
| FD1238B2H-AT00 | 4000 | 1.50 | 18.00 | 169.40 | 287.81 | 16.76 | 0.66 | 59.6 | Red | |||
| FD1238B2M-AT00 | 3000 | 0.80 | 9.60 | 125.93 | 213.96 | 9.19 | 0.36 | 52.4 | Green | |||
| FD1238B2L-AT00 | 2000 | 0.45 | 5.40 | 84.30 | 143.23 | 4.04 | 0.16 | 42.1 | Blue | |||
Product Parameters
The company is committed to providing integrated services of R&D, production, testing and maintenance with intelligent equipment as the leading factor.
| Parameter | Specification |
| Model | XY-GF200 |
| Air Pressure | 800Pa (Max) |
| Air Flow | 15-50 CFM (Adjustable) |
| Voltage | DC 12/24/48V |
| Noise Level | 35-50 dB(A) |
| Power Consumption | 18W-60W |
| Protection Rating | IP55 (Dustproof & Water-resistant) |
