FD7030B

New generation of smart panelAPP*1 upgraded

Adapted to epson weChat app*2

Automatic double-sided printing

Original factory warranty (including print head), nationwide warranty

our company is committed to intelligent to equipment. As the leading R&D, production, testing, maintenance integrated service as the main line, and strive to build us into a strong R&D capability, high product quality, precision experimental data and faster after-sales response of the heat dissipation service Integrated enterprise.

Whatsapp: +86 153 6189 2827

Model	Rated voltage	Voltage range	Speed	Current	Power	Air Flow		Air pressure		Noise	Curve	Weight
Model	VDC	VDC	RPM	A	W	CFM	M3/h	mmH2O	InH2O	dBA	Color	G
FD7030S4U-BP00	24	12~26.4	5000	0.25	6.00	12.48	21.20	36.24	1.43	50.4	Black	56
FD7030S4H-BP00			4000	0.18	4.32	9.77	16.60	22.59	0.89	45.2	Red
FD7030S4M-BP00			3000	0.10	2.40	7.26	12.33	11.01	0.43	39.6	Green
FD7030S4L-BP00			2000	0.06	1.44	6.50	11.04	6.84	0.27	35.4	Blue
FD7030S2U-BP00	12	6~14	5000	0.55	6.60	12.48	21.20	36.24	1.43	50.4	Black
FD7030S2H-BP00			4000	0.40	4.80	9.77	16.60	22.59	0.89	45.2	Red
FD7030S2M-BP00			3000	0.20	2.40	7.26	12.33	11.01	0.43	39.6	Green
FD7030S2L-BP00			2000	0.16	1.92	6.50	11.04	6.84	0.27	35.4	Blue
FD7030S1U-BP00	5	3.5~5.5	5000	1.20	6.00	12.48	21.20	36.24	1.43	50.4	Black
FD7030S1H-BP00			4000	0.80	4.00	9.77	16.60	22.59	0.89	45.2	Red
FD7030S1M-BP00			3000	0.35	1.75	7.26	12.33	11.01	0.43	39.6	Green
FD7030S1L-BP00			2000	0.10	0.50	6.50	11.04	6.84	0.27	35.4	Blue

Product Parameters

The company is committed to providing integrated services of R&D, production, testing and maintenance with intelligent equipment as the leading factor.

Parameter	Specification
Model	XY-GF200
Air Pressure	800Pa (Max)
Air Flow	15-50 CFM (Adjustable)
Voltage	DC 12/24/48V
Noise Level	35-50 dB(A)
Power Consumption	18W-60W
Protection Rating	IP55 (Dustproof & Water-resistant)
