FD6018B

Size:60*60*18mm

Voltage:

Speed:

Bearing: Sleeve/Dual ball

Cable: supoort customization

Connector: support customization

IP Rating: IP54/IP55/IP67/IP68

Function: Reverse connection protection, automatic restart, PWM, FG, RD

Datasheet Download

Whatsapp: +86 153 6189 2827

Model	Rated voltage	Voltage range	Speed	Current	Power	Air Flow		Air pressure		Noise	Curve	Weight
Model	VDC	VDC	RPM	A	W	CFM	M3/h	mmH2O	InH2O	dBA	Color	G
FD6018S4U-BP00	24	12~26.4	5000	0.12	2.88	6.39	10.86	16.02	0.63	41.1	Black	32
FD6018S4H-BP00			4500	0.08	1.92	5.74	9.75	12.07	0.48	37.2	Red
FD6018S4M-BP00			4000	0.05	1.20	5.03	8.55	8.72	0.34	33.4	Green
FD6018S4L-BP00			3500	0.03	0.72	4.09	6.95	6.54	0.26	28.8	Blue
FD6018S2U-BP00	12	6~14	5000	0.20	2.40	6.39	10.86	16.02	0.63	41.1	Black
FD6018S2H-BP00			4500	0.12	1.44	5.74	9.75	12.07	0.48	37.2	Red
FD6018S2M-BP00			4000	0.09	1.08	5.03	8.55	8.72	0.34	33.4	Green
FD6018S2L-BP00			3500	0.06	0.72	4.09	6.95	6.54	0.26	28.8	Blue
FD6018S1U-BP00	5	3.5~5.5	5000	0.30	1.50	6.39	10.86	16.02	0.63	41.1	Black
FD6018S1H-BP00			4500	0.20	1.00	5.74	9.75	12.07	0.48	37.2	Red
FD6018S1M-BP00			4000	0.16	0.80	5.03	8.55	8.72	0.34	33.4	Green
FD6018S1L-BP00			3500	0.10	0.50	4.09	6.95	6.54	0.26	28.8	Blue

Product Parameters

The company is committed to providing integrated services of R&D, production, testing and maintenance with intelligent equipment as the leading factor.

Parameter	Specification
Model	XY-GF200
Air Pressure	800Pa (Max)
Air Flow	15-50 CFM (Adjustable)
Voltage	DC 12/24/48V
Noise Level	35-50 dB(A)
Power Consumption	18W-60W
Protection Rating	IP55 (Dustproof & Water-resistant)
