FD5025B-1

New generation of smart panelAPP*1 upgraded

Adapted to epson weChat app*2

Automatic double-sided printing

Original factory warranty (including print head), nationwide warranty

our company is committed to intelligent to equipment. As the leading R&D, production, testing, maintenance integrated service as the main line, and strive to build us into a strong R&D capability, high product quality, precision experimental data and faster after-sales response of the heat dissipation service Integrated enterprise.

Datasheet Download

Whatsapp: +86 153 6189 2827

Model	Rated voltage	Voltage range	Speed	Current	Power	Air Flow		Air pressure		Noise	Curve	Weight
Model	VDC	VDC	RPM	A	W	CFM	M3/h	mmH2O	InH2O	dBA	Color	G
FD5025B4U-BP00	24	12~26.4	6000	0.14	3.36	7.06	11.99	18.85	0.74	42.5	Black	33
FD5025B4H-BP00			5000	0.08	1.92	5.97	10.14	12.76	0.50	38.8	Red
FD5025B4M-BP00			4000	0.05	1.20	4.47	7.59	6.53	0.26	33.2	Green
FD5025B4L-BP00			3000	0.03	0.72	3.27	5.56	3.09	0.12	28.4	Blue
FD5025B2U-BP00	12	6~14	6000	0.25	3.00	7.06	11.99	18.85	0.74	42.5	Black
FD5025B2H-BP00			5000	0.15	1.80	5.97	10.14	12.76	0.50	38.8	Red
FD5025B2M-BP00			4000	0.08	0.96	4.47	7.59	6.53	0.26	33.2	Green
FD5025B2L-BP00			3000	0.05	0.60	3.27	5.56	3.09	0.12	28.4	Blue
FD5025B1U-BP00	5	3.5~5.5	6000	0.40	2.00	7.06	11.99	18.85	0.74	42.5	Black
FD5025B1H-BP00			5000	0.30	1.50	5.97	10.14	12.76	0.50	38.8	Red
FD5025B1M-BP00			4000	0.20	1.00	4.47	7.59	6.53	0.26	33.2	Green
FD5025B1L-BP00			3000	0.12	0.60	3.27	5.56	3.09	0.12	28.4	Blue

Product Parameters

The company is committed to providing integrated services of R&D, production, testing and maintenance with intelligent equipment as the leading factor.

Parameter	Specification
Model	XY-GF200
Air Pressure	800Pa (Max)
Air Flow	15-50 CFM (Adjustable)
Voltage	DC 12/24/48V
Noise Level	35-50 dB(A)
Power Consumption	18W-60W
Protection Rating	IP55 (Dustproof & Water-resistant)
