FD5010B-2

New generation of smart panelAPP*1 upgraded

Adapted to epson weChat app*2

Automatic double-sided printing

Original factory warranty (including print head), nationwide warranty

our company is committed to intelligent to equipment. As the leading R&D, production, testing, maintenance integrated service as the main line, and strive to build us into a strong R&D capability, high product quality, precision experimental data and faster after-sales response of the heat dissipation service Integrated enterprise.

Datasheet Download

Whatsapp: +86 153 6189 2827

Model	Rated voltage	Voltage range	Speed	Current	Power	Air Flow		Air pressure		Noise	Curve	Weight
Model	VDC	VDC	RPM	A	W	CFM	M3/h	mmH2O	InH2O	dBA	Color	G
FD5010B4U-BP00	24	12~26.4	7000	0.12	2.88	4.53	7.70	21.06	0.83	40.3	Black	16
FD5010B4H-BP00			6000	0.08	1.92	3.84	6.52	14.84	0.58	34.5	Red
FD5010B4M-BP00			5000	0.05	1.20	3.21	5.45	9.39	0.37	29.4	Green
FD5010B4L-BP00			4000	0.03	0.72	2.68	4.55	5.85	0.23	25.2	Blue
FD5010B2U-BP00	12	6~14	7000	0.18	2.16	4.53	7.70	21.06	0.83	40.3	Black
FD5010B2H-BP00			6000	0.15	1.80	3.84	6.52	14.84	0.58	34.5	Red
FD5010B2M-BP00			5000	0.10	1.20	3.21	5.45	9.39	0.37	29.4	Green
FD5010B2L-BP00			4000	0.06	0.72	2.68	4.55	5.85	0.23	25.2	Blue
FD5010B1U-BP00	5	3.5~5.5	7000	0.27	1.35	4.53	7.70	21.06	0.83	40.3	Black
FD5010B1H-BP00			6000	0.20	1.00	3.84	6.52	14.84	0.58	34.5	Red
FD5010B1M-BP00			5000	0.15	0.75	3.21	5.45	9.39	0.37	29.4	Green
FD5010B1L-BP00			4000	0.10	0.50	2.86	4.55	5.85	0.23	25.2	Blue

Product Parameters

The company is committed to providing integrated services of R&D, production, testing and maintenance with intelligent equipment as the leading factor.

Parameter	Specification
Model	XY-GF200
Air Pressure	800Pa (Max)
Air Flow	15-50 CFM (Adjustable)
Voltage	DC 12/24/48V
Noise Level	35-50 dB(A)
Power Consumption	18W-60W
Protection Rating	IP55 (Dustproof & Water-resistant)
